IntegraHeaders
Size: 4″ (10.2 cm), 6″ (15.2 cm) & 8″ (20.3 cm)
Bundle of 30 pieces.
THE INTEGRASPEC DIFFERENCE
IntegraSpec is the original bi‑directional, reversible ICF building system with no top, bottom, left, or right forms. Unlike other ICFs, IntegraSpec® is a patented independent panel form system—not a rigid block—with many advantages such as substantial reductions in inventory, handling, transport, and waste. IntegraSpec is easier and faster to assemble, pour, and keep straight due to its unique, patented interlocking, reversible, independent technology.
INTEGRAHEADERS
IntegraHeaders forms and provides insulation at the top and bottom of rough openings—such as windows and doors. Incorporated dovetailed grooves provide permanent mechanical bonding with the concrete.
Specifications
IntegraHeaders dimensions
4″ (10.2 cm) wide × 1.5″ (3.8 cm) thick × 8′ (244 cm) long
5″ (12.7 cm) wide × 1.5″ (3.8 cm) thick × 8′ (244 cm) long
6″ (15.2 cm) wide × 1.5″ (3.8 cm) thick × 8′ (244 cm) long
8″ (20.3 cm) wide × 1.5″ (3.8 cm) thick × 8′ (244 cm) long
10″ (25.4 cm) wide × 1.5″ (3.8 cm) thick × 8′ (244 cm) long
12″ (30.5 cm) wide × 1.5″ (3.8 cm) thick × 8′ (244 cm) long.
IntegraHeader material
Flame‑retardant Type 2 expanded polystyrene (EPS); density 1.5 lb/ft³ (24.1 kg/m³).
Incorporated dovetail
Provides excellent concrete bonding with EPS.
IntegraHeader 4″ (10.2 cm) details
Quantity: 30 pieces
Packaging: Shrink wrap
Approx. box weight: 50 lb (22.7 kg)
Bundle size: 96″ × 15″ × 12″
(244 cm × 38.1 cm × 30.5 cm)
IntegraHeader 5″ (12.7 cm) details
Quantity: 30 pieces
Packaging: Shrink wrap
Approx. box weight: 53 lb (24.0 kg)
Bundle size: 96″ × 15″ × 15″
(244 cm × 38.1 cm × 38.1 cm)
IntegraHeader 6″ (15.2 cm) details
Quantity: 30 pieces
Packaging: Shrink wrap
Approx. box weight: 56 lb (25.4 kg)
Bundle size: 96″ × 15″ × 17″
(244 cm × 38.1 cm × 43.2 cm)
IntegraHeader 8″ (20.3 cm) details
Quantity: 30 pieces
Packaging: Shrink wrap
Approx. box weight: 62 lb (28.1 kg)
Bundle size: 96″ × 15″ × 24″
(244 cm × 38.1 cm × 61.0 cm)
THE BENEFITS OF INTEGRASPEC®
, 6″ (15.2 cm) & 8″ (20.3 cm)_files/icon-efficacite-ene.png){kind=icon}
ENERGY EFFICIENCY
Owners enjoy energy savings of up to 100% (net zero).
, 6″ (15.2 cm) & 8″ (20.3 cm)_files/icon-stabilite-stru.png){kind=icon}
STRUCTURAL STABILITY
IntegraSpec® offers great protection from high winds in hurricane and tornado areas, withstanding winds in excess of 250 mph.
, 6″ (15.2 cm) & 8″ (20.3 cm)_files/icon-insonorisation.png){kind=icon}
QUIET
STC rating of 50+ (or greater when combined with other sound‑reduction materials).
, 6″ (15.2 cm) & 8″ (20.3 cm)_files/icon-ameliore-quali.png){kind=icon}
IMPROVED AIR QUALITY
Contains no volatile organic compounds (VOCs) and does not support the growth of mould or mildew.
, 6″ (15.2 cm) & 8″ (20.3 cm)_files/icon-protection-hum.png){kind=icon}
MOISTURE PROTECTION
IntegraSpec® helps eliminate moisture and condensation.
, 6″ (15.2 cm) & 8″ (20.3 cm)_files/icon-protection-feu.png){kind=icon}
FIRE PROTECTION
Fire protection for several hours, ensuring superior safety for your family.
, 6″ (15.2 cm) & 8″ (20.3 cm)_files/icon-installation-r.png){kind=icon}
FAST & RELIABLE
By using IntegraSpec ICF, you complete six steps in one application.
, 6″ (15.2 cm) & 8″ (20.3 cm)_files/icon-recyclable.png){kind=icon}
THE ECO-FRIENDLY SOLUTION
100% recyclable material; net zero homes; LEED; Passivhaus; geothermal shell compliant.
, 6″ (15.2 cm) & 8″ (20.3 cm)_files/icon-reduction-dech.png){kind=icon}
REDUCE WASTE ON SITE
Panels are reversible and bi‑directional—eliminating top, bottom, left, and right—which greatly reduces material waste.
